DC Power Supplies by Plating Electronic
POWER STATIONs for highest demands
Whether low or high currents, POWER STATIONs by Plating Electronic offer 50mA to over 20,000A accurately controllable and stable output current.  Universal applications such as testing and installation in cabinets. Tell us your requirements and we will advise you with the optimal POWER STATION solution.
POWER STATONs pe3000
Power supply modules
Output:
max output power range up to 40,000 W
output current 10 to 3,000 A
output voltage 4 to 500 V
Very low control deviation
Precise adjustment accurracy
Voltage and amperage adjustable from 0 to maximum ratings of the unit
Suitable for installation in cabinets
Stainless steel casing
Remote remote control model pe 280
can be programmed to perform optional  functions such as
        - Amp Hour Counter
        - Pre Set Counter
        - Chemical dosing
        - Multi Step Timer
 See data sheet for a list of all the features that can be installed with the pe280

POWER STATONs pe4000
Rack-mount power supplies
POWER STATONs pe2050
Bench top power supplies
Output:
max output power range up to 6,000 W
output current 20 to 600 A
output voltage 4 to 500 V
Suitable for installation in 19" racks
Precise adjustment accuracy
Air cooled
Output:
Guaranteed low ripple (see graph) - improves finish quality
max output power range up to 15,000 W
output current 30 to 2,000 A
output voltage 4 to 500 V
Bench top design
Precise adjustment accuracy
Air cooled
The above represents only a small section of our product line.  Please contact us and request our complete catalog or to discuss your specific needs.
Download
New
Brochure
Low Ripple, Highly Efficient Switch Mode Rectifiers for Metal Finishing
Accuracy of adjustment better than 1% over the entire range of operation, operating range 2%-100% of rated output current.
Energy Efficient / Power factor > 95%
Compact Design: typically units are 1/3 the size & 1/2 the weight of SCR rectifiers - simplifies facilities requirements.
